Powered Roller Conveyor

Powered roller conveyors allow for zoned specific conveyors. A single motorized roller can drive up to eight idler rollers. Rollers are 24 VDC and include a drive card. Multiple rollers can be driven using a single drive card. Powered roller conveyors are also excellent for small tight spaces and short lengths.  The RBM-P 2255 is the perfect zoned roller conveyor.

Select a CAD Model to Configure

Request a Quote

Product Information for Powered Roller Conveyor
  • Lengths: Up to 10,000 mm
  • Widths: 250 mm to 1,524 mm usable
  • Loading: Depends on roller type and conveyor platform
  • Roller Diameters: 1.9 inch
  • Roller Material: Various metals and plastics
  • Roller Pitch: 100 mm
  • Voltage: Drive roller is 24 VDC
  • Speeds: Up to 100 fpm

Catalogs, Resources & Downloads for Powered Roller Conveyor

Technical Specifications for Powered Roller Conveyor
  • Roller Diameter: 1.9″
  • Roller Material: Steel
  • Roller Coatings: PU and PVC
  • Roller Types:
    • Motorized Roller: V-belt driven, one motorized per eight idler rollers required – accumulation is not allowed
    • Motorized Drive Roller: 24 VDC with a control card

Product Options for Powered Roller Conveyor
  • Lane dividers and custom rails
  • Infeed and discharge chutes
  • Work tables
  • Blade stops and transfers
